Dascom TallyCom III Set-up Guide for IBM System i/iSeries/AS400 in TCP/IP environments - Manual (Page 6)

DASCOM AS/400 Set-up Guide Version 2.0 Page 6 of 10
A completed screen looks like this:
3.3 To Configure AS/400 for IPDS printing on V3R7
On the AS/400 command line, enter a command in the form:
CRTPSFCFG PSFCFG(AFP/NETWRKPRT) IPDSPASTHR(*YES) RLSTMR(*SEC15)
TEXT('Print server description')
Create Device Desc (Printer) (CRTDEVPRT)
Type choices, press Enter.
Device description . . . . . . . > TGEIPDS
Device class . . . . . . . . . . > *LAN
Device type . . . . . . . . . . > *IPDS
Device model . . . . . . . . . . > 0
LAN attachment . . . . . . . . . *IP
Advanced function printing . . . *YES
Port number . . . . . . . . . . > 5001
Online at IPL . . . . . . . . . *YES
Font:
Identifier . . . . . . . . . . > 11
Point size . . . . . . . . . . *NONE
Form feed . . . . . . . . . . . > *CONT
Separator drawer . . . . . . . . *FILE
Separator program . . . . . . . *NONE
Library . . . . . . . . . . .
Printer error message . . . . . *INFO
Message queue . . . . . . . . . *CTLD
Library . . . . . . . . . . .
Activation timer . . . . . . . . 170
Image configuration . . . . . . *NONE
Maximum pending requests . . . . 6
Print while converting . . . . . *YES
Print request timer . . . . . . *NOMAX
Form definition . . . . . . . . F1C10110
Library . . . . . . . . . . . *LIBL
Remote location:
Name or address . . . . . . . > '172.20.70.21'
User-defined options . . . . . . *NONE
If set to *INQ, then the
intervention (error) will require
an operator input to retry or to
cancel the writer. If the
parameter is set to *INFO, the
driver continues to retry until
the connection has been
established or TCP/IP has
closed the socket. If the
connection is eventually
successful, the intervention
message is attempted to be
removed from the message
queue and process continues.
Set *CONT for matrix printers.
Set *AUTOCUT for page
printers (laser).
5001 is the IPDS default port
of TGNet print servers.
‘11’ Sets the standard IPDS
font (COURIER NLQ @10cpi)
