Dascom 7206 Peeler Installation and User Guide - Manual (Page 5)

– 5 –
2-2 Connecting the peeler unit cable
Connect the peeler unit cable connector to the receptacle of the printer after
setting the peeler cable in the printer housing.
Note: Set the peeler cable (A) not to touch the print head-up spring (B) of the me-
chanism unit.
It is allowed to set the peeler cable under the paper feed motor instead of
the side of the paper feed motor.
A A
B
