4 Peeler specifications
4 Peeler
specifications
Width of liner (a)
: 1
− 4.65 in (25.4 − 118 mm)
Length of label (b)
: 1
− 4.72 in (25.4 − 120 mm)
Label: fine media/Thickness: 0.09 mm
(including glue layer)/Rolled inwards
Minimum width of label (c)
: Label must be positioned at 0.63
− 0.87in
(16
− 22 mm) from left edge of liner,
which is viewed from front of media exit
Maximum width of label
: To be narrower than liner
Thickness of label
: 0.0067 in (0.17 mm) or less
Thickness of liner
: 0.0027 in (0.07 mm) or less
Maximum diameter of roll media : 8 in (203 mm)
Inner diameter of roll media
: 3 in (76 mm) or more
g
n
i
s
u
n
e
h
w
(
s
l
e
b
a
l
d
e
l
e
e
p
n
o
il
li
m
e
n
o
r
o
m
k
0
0
1
:
y
t
il
i
b
a
r
u
D
the label above)
Peeling position accuracy
:
±1.0 mm
Peeling position varies depending on the type of
media, the size of roll media and the size of ink
ribbon, so adjust it to the optimum condition as
needed
c
a
b
Direction of media feed
