Dakota Ultrasonics

Dual-Multi Mode

Often times users and inspectors in the field are faced with coated

materials such as pipes and tanks. Typically inspectors will need to

remove the paint or coating prior to measuring, or allow for some fixed

amount of error introduced by the paint or coating thickness and velocity.

An A-Scan scope with a special echo -echo mode is generally used in order

to accurately perform measurements through paints and coatings.

However, In order to inspect for blind wall pitting and internal flaws, both

echo-echo (thru-paint / coatings), and pulse-echo (locate flaws & pits)

modes are needed. Special high damped dual element transducers are

also a must when performing inspections using both modes without an a-

scan scope for verification. A highly damped transducer rings for a much

shorter time, allowing the MMX-6DL to measure thinner material

thicknesses in echo-echo mode. This same transducer is equally effective

when used in pulse-echo mode, eliminating the need to use different

transducers for each mode. The new MMX-6DL gives you all these

features in a simple to use, one button toggle, digital thickness gauge. The

following steps outline the procedure for setting up this feature:

Dual-Multi Mode

1) Press ON/OFF key to power up the MMX-6 DL.

2) Press MODE key to activate features and settings.

3) Press the UP or DOWN arrow keys to scroll to GAtE.

4) Press the SEND key to toggle between modes ( E-E, P-E).
