Appendix A — Specifications
MODEL MPTZ766A
MODULE
CCD Type 1/4" Type Super HAD CCD II
Optical Zoom 22X
Max Resolution 580 TVL
Focal length f = 3.9mm ~ 85.8mm
Angle of view
3.9mm – 49.5° (H)
85.8mm – 2.4° (H)
F-Number F1.6 – F3.7
Min. Illumination
- Normal 0.5 Lux
ICR on (Day & Night) YES
Motion Detection (in PRESET) YES
DOME
Tilt angle 0° ~ 90° (Auto Flip)
Auto Calibration 0.1° ~ 6°
Panning angle 360 continuous rotation
Alarm 1 input (NC/NO), 1 TTL output
Auto Scan 1 auto pan & 4 auto scan capability
Preset 120 presets
Tour 4 tours (consist of 42 presets / 1 tour)
Max Speed 240° /sec.
Area Title it can be divided 8 areas with 12 characters of title
Electrical
Power Source 12Vdc ± 10%
Power Consumption 8W (650mA)
Control RS-485, baud rate: 2400~19.2k bps (default: 9600 bps)
ID (Camera Address) 1 ~ 255
Mechanical
Dimension See diagram
Weight Approx. 1.1 kg for dome
Environment
Operating temperature 0
°
C to 40
°
C (32
°
F to 104
°
F)
Operating humidity 0 to 90%RH (non-condensing)
Storage temperature -20
°
C to 60
°
C (-4
°
F to 140
°
F)
* Specifications are subject to change without notice *
