FT SB 08
15 FT SB 08
E
N
DOOR LOCK TIME 01
AUDIO TIMING
10
WAITING TIME 10
NAME DIRECTORY
ACCESS CONTROL
SETTINGS
SIMPLEBUS
Select the SETTINGS/
SYSTEM PARAMETERS /
SPEAKER
PARAMETERS/ VIEWING
menu.
Scroll through the
displayed information using
the
keys.
Configuration mode has
been accessed (see point 3
in FT SB 08, page 20).
The parameters set on the
porter Art. 1602/4660
module are displayed.
CAUTION:
The function is only
guaranteed with porter
modules
Art. 4660 (R.I. 032),
Art. 4660C (R.I. 013),
Art. 1602 (R.I. 027).
DISPLAY DESCRIPTION OPERATION
PAGE 12
10B) Displaying the SPEAKER PARAMETERS Art. 1602 - 4660
(lock-release, audio and await reset time plus operating mode for Simplebus or
Simplebus Top).
Module Art. 1602 / 4660
powered with PR terminal
connected to terminal -.
During the calling procedure, if the first digit of the code is entered, Art. 3340 displays the
list of codes stored in the directory which begin with that digit.
At this point you can enter the next characters to reduce the number of codes on the list,
or you can simply scroll through the available codes.
The alphanumeric indirect codes and corresponding names can only be entered from a
PC using the software Art. 1249/A; the codes must consist of one or more digits, followed
by optional alphabetical characters.
By entering the name directory menu, it is possible to modify the name and Simplebus
code, but the alphanumeric code cannot be altered.
9.4) IMMOTEC STANDARD call mode
Digital module Art. 3340 can be used in conjunction with the Simplekey module Art.
SK9001, Art. SK9020 by connecting the two products via RS 485 (see diagram on page
58).
In this configuration, the use of Simplekey access keys (badges) automatically allows
entry of the corresponding code/name (new key) or updating of name only (if the code
already exists) in the directory of digital module Art. 3340. Since a single user code
(apartment) can have up to 2 access keys associated with it under different names,
during a numerical code call from the digital module the first name of the 2 in alphabetical
order will be displayed.
NOTE: Names cannot be entered and modified manually. Badge acquisition only takes
place when digital mode is in standby.
9.5) IMMOTEC INDIRECT call mode
Digital module Art. 3340 can be used in conjunction with the Simplekey module Art.
SK9001, Art. SK9020 by connecting the two products via RS 485 (see diagram on page
58).
In this configuration the use of access keys allows automatic updating of the Simplekey
access key (badge) name only, as it appears in the directory of digital module Art. 3340.
The immotec indirect codes and corresponding names can only be entered from a PC
using the software Art. 1249/A. Since a single user code (apartment) can have up to 2
access keys associated with it under different names, during a numerical code call from
the digital module the first name of the 2 in alphabetical order will be displayed.
NOTE: Names cannot be entered and modified manually. Badge acquisition only takes
place when digital mode is in standby.
