chiliGREEN P4VTB - Manual (Page 6)

3
English
1. P4VTB Features
A. Hardware
CPU
Provides Socket 478.
Supports the Intel
®
Pentium 4 Processor.
Front Side Bus at 400/533/800 MHz.
Chipset
North Bridge: VIA PT800
South Bridge: VIA VT8237.
Main Memory
Supports up to 2 DDR devices.
Supports 200/266/333/400 MHz DDR devices.
Maximum memory size of 2GB.
Super I/O
Chip: ITE IT8705.
Slots
Five 32- PCI bus master slots.
One AGP slot.
One CNR slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Bride Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
Serial ATA
Chip: VT8237
Supports RAID 0, 1.
Supports 2 Serial ATA (SATA) ports.
- compliant with SATA 1.0 specification.
- Data transfer rates up to 1.5 GB/s.
On Board AC’97 Sound Codec
Chip: CMI9739A.
Compliant with AC’97 specification.
AC’97 2.2 interface.
Supports 6 channels.
On Board Peripherals
a. Rear side
2 serial ports.
1 parallel port. (SPP/EPP/ECP mode)
Audio ports in vertical position.
