Operating
12 LMC20-GB
5.4 Soft Start Timer
The soft start timer is used to start a process at a reduced setpoint and power. The soft start
setpoint is used as a threshold only and is not a control point.
Example:
Main Setpoint = 800°C
Max power limit = 75% (This maybe set at the factory)
Soft Start Setpoint = 600°C (Threshold)
Soft Start Power Limit = 50% (Cannot be set above max power Limit)
When the timer is running the maximum power is controlled by the Soft Start Setpoint of
600°C and the Soft Start Power limit of 50%, this will continue until the timer ends or the PV
(Process value) exceeds the Soft Start Setpoint.
When the timer ends or the PV exceed the Soft Start Setpoint the instrument will start to
control using the main Setpoint of 800°C and the Max Power Limit of 75%.
Press scroll
 until the display shows TM.CFG <TIMER CONFIGURATION>. Using the Up 
Down
 select SF.st
When Soft Start parameter is selected, the Timer resolution (
TM.RES), Time duration (DWELL),
Soft Start Setpoint (
SS.SP) and Soft Start Power Limit (SS.PWR) functions become available.
Press scroll
 until the display shows TM.RES < Time resolution >. Use the Up 
Down
 to select the timer units in Min or Hours.
Press scroll
 until the display shows DWELL < SET TIME DURATION >. Use the Up 
Down
 to enter the time duration required, before the output power switches on.
Press scroll
 until the display shows SS.SP < Soft Start Setpoint >. Use the Up 
Down
 to enter the soft start setpoint.
Press scroll
 until the display shows SS.PWR < Soft Start Power Limit >. Use the Up 
Down
 to enter the soft start power limit.
