8.0 F USES & P OWER S ETTINGS
8.1 Fuses
F1-F3: Refer to the circuit diagrams.
F1
Internal
supply fuses Fitted if supply cable fitted.
Fitted on-board to some types of EMC filter. on-board and up to 16 Amps:
32mm x 6mm type F
other: GEC Safeclip
F2
Auxiliary
circuit fuses Fitted on-board to some types of EMC filter.
May be omitted up to 10 Amp/phase supply rating. 2 Amps glass type F
On board: 20mm x 5mm
Other: 32mm x 6mm
F3
Heat Light
fuses May be omitted up to 25 Amp/phase supply rating. 2 Amps glass type F
32mm x 6mm
Customer
fuses Required if no supply cable fitted.
Recommended if cable fitted. See rating label for
amperage; see table below
for fuse rating.
Model phases Volts Supply Fuse Rating
RHF 14/3 1-phase 200-240 32A (or 30A)
RHF 14/3 2-phase + N 380/220 - 415/240 16A/ph (or 15A)
RHF 15/3,16/3 1-phase 200-240 40A
RHF 15/3,16/3 2-phase + N 380/220 - 415/240 20A/ph
RHF 14/8 1-phase 200-240 63A
RHF 14/8 2-phase + N 380/220 - 415/240 32A/ph (or 30A)
RHF 15/8,16/8 1-phase 200-240 63A
RHF 15/8,16/8 3-phase + N 380/220 - 415/240 20A/ph
RHF 15/8,16/8 3-phase delta 220-240 32A/ph
RHF 15/8,16/8 3-phase delta 208 40A/ph
RHF 14/15 3-phase + N 380/220 - 415/240 25A
RHF 14/15 3-phase delta 220-240, 208 40A/ph
RHF 15/15,16/15 3-phase + N 380/220 - 415/240 25A/ph
RHF 15/15,16/15 3-phase delta 220-240, 208 50A/ph
RHF 15/15,16/15 3-phase + N 380/220 - 415/240 25A/ph
RHF 15/15,16/15 3-phase delta 220-240, 208 50A/ph
RHF 14/35, 15/35 3-phase + N 380/220 - 415/240 40A/ph
RHF 14/35, 15/35 3-phase delta 220-240, 208 63A/ph
RHF 16/35 3-phase + N 380/220 – 415/240 40A/ph (see note)
RHF 16/35 3-phase delta 220-240, 208 63A/ph (see note)
380-415V 3-wire: same ratings as 3-phase+N
RHF 16/35 – technical note.
All phases should be fused as indicated: the same wire size is used in all three internal circuits. For the
delta configuration the furnace power is set lower to bring the rated current below 63 Amps. The current
ratings for the three phases are:
380/220 – 415/240 208-240 delta
Furnace Power 16000W 15000W
Phase 1 40 Amps 63 Amps
Phase 2 40 Amps 48 Amps
Phase 3 20 Amps 48 Amps
