6
Quadra Instructions 9-30-13
1.3 Comb Specifications for Hand Cast Gels
1.4 Safety
Power to the Quadra Electrophoresis System is to be supplied by an external DC volt-
age power supply that must be ground isolated so that the DC voltage output floats
with respect to ground. For any power supply used, the maximum specified operat-
ing parameters for the units are:
Maximum Limits
300 VDC
30 watts power
190mA current
60°C ambient temperature
Current to the unit, provided from the external power supply, must enter the unit
through the lid assembly, providing a safety interlock to the user. Current to the unit
is broken when the lid is removed.
Do not attempt to use the unit without the
safety lid, and always turn the power supply off before removing the lid, or when
working with the unit in any way. Follow safety precautions specified by the
power supply manufacuturer.
COMB OPTIONS, material: PTFE, tooth depth: 9.5mm, overall length: 7.9cm
Cat. # # of
Teeth
Thickness of
Teeth (mm)
Width of
Teeth (mm)
Recommended Max.
Sample Vol./Well (µl) *
MVX-0701 1 0.75 66.6 356
MVX-0710 10 0.75 5.23 28
MVX-0714 14 0.75 3.3 19
MVX-0716 16 0.75 2.92 16
MVX-1001 1 1.0 66.6 474
MVX-1010 10 1.0 5.23 37
MVX-1014 14 1.0 3.3 24
MVX-1016 16 1.0 2.92 21
MVX-1501 1 1.5 66.6 712
MVX-1510 10 1.5 5.23 56
MVX-1514 14 1.5 3.3 35
MVX-1516 16 1.5 2.92 31
* Maximum loading volume is calculated by taking 75% of the total tooth volume.
