III. Description of product

A. Display Section

B. Harness section

※ On some Nissan vehicles, you have to unplug the IGN wire and change the power source to the

cigarette lighter.

ENTER Switch

UP Switch

RIGHT Switch

(PEAK Clear)

Infrared

Port

LEFT Switch

(MENU)

DOWN Switch

Display Harness
(Black, 5 feet)

Main Harness (Black, 30cm)

IGN (White, Female)

IGN (White, Male)

IGN/ACC Harness (Black Female)

Self-diagnosis
Connector
(Female)

Cigarette plug adaptor
