II. Product’s Characteristics.

A. This product is designed to monitor and display the signals from the ECU using the

self-diagnosis connector that has been in based on by the International Standards ISO

14230 since 1996.

B. Characteristics

1. Can be easily connected to the coupler.

2. There is no need for additional installation of sensors.

3. There is no need for complicated wiring since power can be supplied from the cigarette

lighter.

4. Basically it can show 20 varieties of displays, and by combining the varieties, it can show

over 100 different displays.

5. It is possible to display more different displays by connecting with the SBC-iD. Moreover,

by inputting the vehicle speed signal, the SBC I-D can set the boost based on the

vehicle’s speed.

6. It is equipped to display the peak value, warning function, and record/replay function as

standard equipments.

7. It is designed to work on many different brands of vehicles and models. As a

result, it is possible to utilize one R-VIT with many other vehicles.

C. Items that can be monitored.

The list below is what this product is designed to monitor from the original ECU’s data

Vehicle Speed

SPEED

RPM

TACHO

Water Temp

WATER

Ignition Timing

IGNT

Injection Timing

INJCT

Injection %

INJCT

Intake Temperature

INTAK

Air Flow Voltage

AIRFL

Boost Pressure

IN-MF

O2 Sensor Voltage

Rear O2 Sensor Voltage

O2R

Air to fuel mixture

A/F-C

Battery Voltage

BATT

Throttle Positioning

Sensor Voltage

THROT

Boost solenoid valve

open ratio

WGV1

Boost solenoid valve

open ratio

WGV2

Automatic

Transmission Fluid

Temperature

AT-FL

Gear Position

GEAR

Four Wheel Drive Ratio

4WD

Vehicle Diagnosis.

※Depending on the vehilce, it may have some differences on the items and number that can be monitored.

Please check with the vehicle compatibility list that is supplied or contact us for more information.
