Convection Oven Component Replacement
35
Table 1. COq Parts
ITEM # PART # QTY DESCRIPTION
1 M0104
M0105
CP0010 4 BLOWER MOTOR, 230 V
BLOWER MOTOR, 208 V
CAPACITOR, 2 mfd
2 FN0037 4 FAN IMPELLER
3 C0156
C0154 4 HEATING ELEMENT, 208 V
HEATING ELEMENT, 230 V
4 LI033UK 6 LAMPHOLDER BODY
5 LI034UK 6 GASKET, LENS
6 LI035UK 6 FRAME, LENS
7 LI038UK 6 LENS, LAMPHOLDER
8 LI037UK 6 REPLACEMENT BULB, 25 W, 230 V
9 T0105 4 THERMOSTAT, HIGH LIMIT
10 S0355 1 SWITCH, MICRO
11 S0363 1 SWITCH, MAGNETIC REED
12 T0170 1 TEMPERATURE PROBE, AIR
13 FN0012
CS0022 2 COOLING FAN
CORDSET
14 SCR315 8 SCREW, #6-32 X 2”
15 G0119 1 GASKET, INNER DOOR SEAL
16 WB30126000
WB30120900 1 FAN COVER (AMERICA)
FAN COVER (EUROPE)
17 L0116 & L0118
NU059UK 4
2 QTR. TURN LATCH (AMERICAS)
NUT, M6 KNURLED (EUROPE)
18 FB30128203 2 DRIP TRAY (OVENS w/ DRAWERS ONLY)
19 R0031 2 SIDE SUPPORT, RACK
20 R0032 5 OVEN RACK, FULL SIZE
