Parts List
No.
Part No.
Description
QTY
Remarks
1
44120001
Drv. Fr. Tower
1
2
44120002
Drv. Rr. & Psgr. Fr. Tower
2
3
44120003
Psgr. Rr. Tower
1
4
44120004
Rear Cross Beam
1
4.1
14121001
Cover
4
4.2
3C000801
Z Cross bolt
4
M6X10
4.3
3C000802
Flat washer C
4
d6
5
44120005
Cross beam parts 2
1
6
44120006
Drv. Runway
1
6.1
24120001
Drv. Runway Weld.
1
6.5
3C000803
Big washer A & C
3
d5
6.6
3C000804
Z Cross bolt
3
M5X12
6.7
34121003
Hose Clamp
3
6.8
14121002
Safety transmission pole clasp
1
φ6
6.9
3C000805
Hexangular nut
2
M6
6.11
3C000806
Hexangular bolt C
2
M10X30
6.12
3C000807
Flat washer C
4
d10
6.13
3C000850
Cable Securing Bolt
4
6.14
14121003
Profiled bar connection
1
6.17
34121003
U Bolt
1
φ8
6.18
3C000808
Hexangular nut
2
M8
6.19
3C000809
Spring washer
2
d8
6.21
3C000810
Flat washer C
2
d8
7
42120007
Psgr. Runaway
1
7.1
3C000811
Hexangular bolt C
9
M10X35
7.2
3C000812
Hexangular nut C
9
M10
7.3
3C000813
Flat washer C
9
d10
7.4
3C000814
Hexangular bolt C
3
M10X25
9
14121004
Front board
2
10
14121005
Small wheel
4
10.1
3C000815
Spring washer A
4
10.2
3C000816
Hexangular nut
4
M12
10.3
3C000817
Flat washer
4
d12
11
14121006
Front wheel block
2
11.1
3C000818
Hexangular bolt C
4
M10X60
13
3C000819
Hexangular nut
8
M20
14
3C000820
Flat washer C
4
d20
15
24120002
Safety ladder
4
Jointing parts
