Wiring – APG ACF-10 user manual User Manual
Page 8
Rev. 1a, 2/03
ACF-10 Series
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
7
• Wiring
1
Supply Voltage: 24-264V AC/DC
Relay Contact Output: 240V 2A AC
(resistive load)
2
3
NO
4
Line
