Rev. A2, 11/08

IRU-2xx4/3xx4

9

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

PARAMETERS

The Parameters (E) command displays the current settings of the sensor. The
following is an example of a parameter report from the IRU-2XX4/3XX4.

PARAMETERS MENU

Min.

Max.

Distance Sensor Number EE

0

9

Bank Number EE

0

9

Blanking EE

152

7620

Pulses EE

0

20

Sensitivity EE

0

100

Calibration EE

0100

1999 (0 .100 to 1.999)

Temp. Compensation

0

1

Average EE

1

10

Out of Range Span EE

0

7620

Out of Range Count EE

0

250

Sample Rate EE

23

1000

Trip point begin

0

7620

Trip point end

0

7620

Trip point type

0

7

Sensor Transmit

0

1 (0 = OFF, 1 = ON)

The IRU-2XX4/3XX4 will display the distance to a target in millimeters.

DISTANCE SENSOR

To request the Distance and temperature from sensor number 1, send:

Send

Receive

AAh

Start Byte

66h

Start Byte

01h,

Sensor Number

01h

Sensor Number

24h

Command

24h

Command

00h

Data (not used)

##h

Distance (High Byte)

00h

Data (not used)

##h

Distance (Low Byte)

55h

End Byte

##h

Temperature

99h

Stop Byte
