Rev. A2, 11/08

IRU-2xx4/3xx4

21

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

To read the End Trip Distance in sensor number 1 , use the command structure:

Send

Receive

AAh

Start Byte

66h

Start Byte

01h,

Sensor Number

01h

Sensor Number

19h

Command

19h

Command

00h

Data (not used)

##h

Distance (High Byte)

00h

Data (not used)

##h

Distance (Low Byte)

55h

End Byte

##h

NA

99h

Stop Byte

To change the Begin trip distance in sensor number 1 to 1200mm, use the
command structure;

Send
AAh

Start Byte

01h,

Sensor Number

1Ah

Command

04h

Data (high byte) 1,200 mm decimal = 4B0h

B0h

Data (low byte)

55h

End Byte

To read the Trip Type in sensor number 1 , use the command structure:

Send

Receive

AAh

Start Byte

66h

Start Byte

01h,

Sensor Number

01h

Sensor Number

1Bh

Command

1Bh

Command

00h

Data (not used)

##h

Trip Type (High Byte)

00h

Data (not used)

##h

NA (Low Byte)

55h

End Byte

##h

NA

99h

Stop Byte

To change the Trip Type in sensor number 1 to 4, use the command structure;

Send
AAh

Start Byte

01h,

Sensor Number

1Ch

Command

04h

Data

84h

NA

55h

End Byte
