Rev. A2, 11/08

IRU-2xx4/3xx4

5

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

DESCRIPTION

The IRU-2xx4/3xx4 is a low cost ultrasonic sensor used for non-contact measure-
ment over a 1’ to 35’ range. RS-485 interface allows for convenient sensor
communication. The sensor is encased in a sealed chemical resistant housing
and has built in temperature compensation.

SPECIFICATIONS

IRU-2xx4

IRU-3xx4

Range:

1’ to 25’

1.25’ to 35’

Housing:

ABS or PVC

PVC

Outputs:

RS-485 & NPN

RS-485 & NPN

Supply Voltage:

12 to 28 VDC

12 to 28 VDC

(24 VDC Recommended sensor performance
is diminished if lower voltage applied)

Current Draw:

60 ma @ 24 VDC

60ma @ 24VDC

2.0 Watts Max.

2.0 Watts Max.

Transducer Type

Ceramic

Ceramic

Ratings

NEMA 4X

NEMA 4X

Sensor adjust

RS-485 interface

RS-485 interface

Operating temp.

-40 to 60 °C

-40 to 60 °C

Resolution

.1inches (2.5mm)

.1inches (2.5mm)

Accuracy

+/- 0.25% Range

+/- 0.25% Range

Temp. Comp.

Internal

Internal

(thermistor located on transducer face)

Sample Rate

Programmable, 1 to 22 Hz

Beam pattern

9 degrees off axis (when operating with
high sensitivity)

Cable

6 conductor, 22 gauge 6’ length
