Rev. A1, 4/07 PWS Series
13
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Spare Parts
Model Description Part Number
PWS-X-ACC-C PWS-X PC Cover 22408
PWS-X-ACC ( ) PWS-X Motor (specify voltage) On Request
PWS-X-ACC ( ) PWS-X Motor assy w/microswitch On Request
(specify voltage)
PWS-X-ACC10 PWS-X Flange, SS304, JIS 5 K 65 A 22905-0019
2 mm thick
PWS-X-ACC2 Motor (110 VAC) 22293
PWS-X-ACC3 PWS-X 4 vane (PC) paddle 22103
(80 mm dia. x 30 mm)
PWS-X-ACC4 PWS-X 1 vane (SS304) paddle 22175
(60 mm dia. x 30 mm)
PWS-X-ACC6 PWS-X2 vane (SS304) paddle 22905-0015
(150 mm dia. x 60 mm)
PWS-X-ACC7 PWS-X 2 vane (PC) paddle 22905-0016
(150 mm dia. x 60 mm)
PWS-X-ACC8 PWS-X 2 vane (SS304) paddle 22905-0017
(80 mm dia. x 35 mm)
PWS-X-ACC9 Motor Assy (110 VAC) w/ microswitch 22905-0018
• Troubleshooting
Symptom
Paddle is covered by material. Relay de-energized.
Possible Causes
• Power Supply not connected.
• Insuffi
cient power supplied.
• Miswiring
• Material too light.
• Material has bridge or angle of repose.
