Parts list, Staking table - 10’ starter kit – Anchor FIESTA FRAME TENT 18-22 User Manual
Page 3
Note: See page 9 for staking layout sample.
3
* (2) RAFTERS HAVE PTEB-3 ATTACHED
PARTS LIST
STAKING TABLE - 10’ STARTER KIT
Part
Description
Quantity
1” x 30” Single Head
Stake (3704201)
4*
1” Web Guy with
Ratchet (22010)
4
*
IMPORTANT NOTE: REFER TO CAUTION STATEMENT #2 FOR IMPORTANT WARNING ABOUT NUMBER OF
STAKES SUPPLIED. (SEE BACK PAGE OF THIS MANUAL)
THE INSTALLER MUST USE THE LOCAL SOIL CONDITIONS TO CALCULATE THE ACTUAL
NUMBER OF STAKES REQUIRED AND IS RESPONSIBLE FOR THE STAKING PATTERN AND
CONFIGURATION.
ANCHOR PROVIDES ANCHORING PACKAGES FOR COMMON SOIL CLASSIFICATIONS;
CONTACT YOUR TENT SALES REPRESENTATIVE FOR MORE INFORMATION.
