Anchor CENTURY FRAME TENTS 10X10, 15X15, 5M AND 20X20 - Manual (Page 5)

5
Raise opposite side by repeating Step 4.
Attach remaining uprights.
Plumb uprights.
Firmly tension all guy webs before proceeding further.
CAUTION: When raising for third upright, one other
upright (see illustration) may be lifted from ground and
be lifted from ground and become unattached.
(SEE STEP 5)
Determine proper mating of 2-piece walls with labels on
the inside. Slide tabs at top of walls into bottom outside
channel opening (see Century Frame extrusion drawing
on Page 3) Orient walls so that beading (kedar) edges
are adjacent to uprights and the lace edges meet in the
middle.
10’x10’ - 5’-1”
15’x15’ - 7’-4”
5Mx5M - 8’-1”
20’x20’ - 9’-9”
Center Poles must be
adjusted to the height
on the illustration
shown. Turn the top of
the center pole in the
direction noted to meet
the required dimension.
7
8
Potential Hazard (see
Caution in Step 7)
LIFT OTHER SIDE
INSTALLING OPTIONAL WALLS
