40’ NAVI-TRAC COMPONENT LIST
CONTINUED FROM PREVIOUS PAGE
6
I.D.
40’ GABLED END NAVI-TRAC
LABEL
(LETTER ON
DRAWING)
COMPONENT DESCRIPTION
CODES
(STAMPED OR
TAPED)
GBL
KIT
1
GBL
KIT
2
HIP
KIT
3
20’
MID
STR
20’
MID
EXT
15’
MID
STR
15’
MID
EXT
10’
MID
STR
10’
MID
EXT
CABLES
**OPTIONS OF 10’,15’, OR 20’ BAYS MUST
BE SPECIFIED.
X-1
UPRIGHT X-CABLES FOR 10’ MID BAY**
GREEN
NAV-BAY10-U8
[4]
[4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-2
UPRIGHT X-CABLES FOR 15’ MID BAY**
GREEN
NAV-BAY15-U8
[4]
[4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-3
UPRIGHT X-CABLES FOR 20’ MID BAY**
GREEN
NAV-BAY20-U8
[4]
[4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X4
LOWER ROOF X-CABLES FOR 10’ MID BAY
A**
RED
NAV-BAY10
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X5
LOWER ROOF X-CABLES FOR 15’ MID BAY
A**
RED
NAV-BAY15
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X6
LOWER ROOF X-CABLES FOR 20’ MID BAY
A**
RED
NAV-BAY20
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X7
UPPER ROOF X-CABLES FOR 10’ MID
BAYS**
BLUE
NAV40-BAY10
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X8
UPPER ROOF X-CABLES FOR 15’ MID BAY
B**
BLUE
NAV40-BAY15
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X9
UPPER ROOF X-CABLES FOR 20’ MID BAY
B**
BLUE
NAV40-BAY20
4
4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
BOLTS AND HARDWARE
LANYARD ASS’Y W/HAIRPIN COTTER
4
1/2”-13 x 3” BOLT W/NYLOCK NUT
6
4
10
2
2
2
2
2
2
1/2”-13 x 3 1/2” BOLT W/NYLOCK NUT
6
6
INSTALLATION TOOLS
CROSS CABLE FOR 40’
BLUE
1
1
1
1
1
1
LOWER SAFETY STRAP W/RATCHET
4
UPPER SAFETY STRAP FOR 10’ BAYS
4
UPPER SAFETY STRAP FOR 15’ BAYS
4
UPPER SAFETY STRAP FOR 20’ BAYS
4
1/2” TENSION LOCK PIN (FOR CROSS
CABLE)
2
2
2
2
2
2
LONG LIFTING CRADLE
1
PUSH POLE EXT. (FOR LONG CRADLE)
1
SHORT LIFTING CRADLE
1
ADJ. BASEPLATE GUIDE BAR
2
FABRIC PULL ROPES
2
WHEELED PANEL GUIDES
2
DROP CLOTH (8’ x 30’)
1
(2) DIAGONAL BEAM BRACES
(SEPARATE PURCHASE)
Other component notes:
1. For X-Cables for units 100’ or longer, see page 13 for quantities and installation.
2. Stakes and Guys are not included in this table. See staking guidelines on Page 9.
