40’ NAVI-TRAC COMPONENT LIST
A MINIMUM GABLED UNIT CONSISTS OF (1) KIT #1, (1) KIT #2 AND (2) EXTENSION MIDS. TO EXTEND THE LENGTH
FURTHER, SIMPLY ADD ADDITIONAL EXTENSION MIDS. STARTER MIDS REQUIRED WITH HIP ENDS ONLY.
CONTINUED ON NEXT PAGE
5
I.D.
40’ GABLED END NAVI-TRAC
LABEL
(LETTER ON
DRAWING)
COMPONENT DESCRIPTION
CODES
(STAMPED OR
TAPED)
GBL
KIT
1
GBL
KIT
2
HIP
KIT
3
20’
MID
STR
20’
MID
EXT
15’
MID
STR
15’
MID
EXT
10’
MID
STR
10’
MID
EXT
EXTRUSIONS W/CHANNELS
E20
EAVE - FEMALE 20’
4
ER10
EAVE/RIDGE - DROP-IN 10’
3
3
ER15
EAVE/RIDGE - DROP-IN 15’
3
3
ER 20
EAVE/RIDGE - DROP-IN 20’
3
3
EE-10
EAVE/GABLED END, DROP-IN 10’
1
1
EW-15
EAVE/GABLED END, DROP-IN 15’
2
2
H21-4
HIP LOWER SPLICE 21-4 (2 pc) 21’-4 (40’)
2
H7-6
HIP UPPER SPLICE (2PC) 7’-6 (40’)
2
R21-9
RAFTER 21’-9
2
1
2
2
2
2
2
2
BRACES
B1
BRACE, HIP 14’ (W/LANYARDS)
4
B3
BRACE, RIDGE 9’-6”
1
1
1
1
1
1
B4
BRACE, UPRIGHT, 3’-9”
1
2
2
2
2
2
2
PURLINS
P1
PURLIN 10’
2
2
2
2
P2
PURLIN 15’
2
2
P3
PURLIN 20’
2
2
UPRIGHTS
U8
UPRIGHT - 8’
2
3
2
2
2
2
2
2
UG-15
END UPRIGHT - 14’-2”
2
2
WELDMENTS, FITTINGS & PLATES
BFW
ADJ. BASE PLATES W/INSERTS (FIXED)
“END”
2
2
3
2
2
2
BHW
ADJ BASE PLATEW/INSERTS (HINGED)
2
2
2
2
2
CW
CORNER WELDMENTS
2
EIW
END INTERMEDIATE WELDMENTS
1
MLW
MID LEFT WELDMENTS
2
2
2
MRW
MID RIGHT WELDMENTS
2
2
2
MCW
MID CENTER WELDMENTS
2
2
2
2
RW
PEAK/RIDGE WELDMENT
1
1
1
1
1
1
RWE
GABLED END RIDGE WELDMENT
1
1
GRW
GABLED END UPRIGHT RAFTER WELD.
2
2
UGT
GABLED END UPRIGHT TOP INSERT
2
2
XRB
X-CABLE RAFTER BRACKET
8
8
TFW
TOP FITTING (END RAFTER) W/HDWR
1
EFW
END FITTING (HIP/INT. RAFTER) W/HDWR
4
