AMMCO 8899 Tool Kit for Non-vented Rotors User Manual
Page 2
Item Part No. Qty. Description
1
906914 2
Tool Bits, Six-edge Carbide
2
910701 1
Tool Bit Assembly, RH
Bit, Screw & Holder
3
910702 1
Tool Bit Assembly, LH
Bit, Screw & Holder
4
910651 1
Tool Bit Assembly, RH
910650 1
Tool Bit Assembly, LH
(Not Shown)
5
909249 2
Screw, Set
6
906841 2
Pin
7
910711 1
Extractor, Spring
8
906905 2
Spring
910710 08/06 2 of 2
© COPYRIGHT 1986 HENNESSY INDUSTRIES AND AMMCO TOOLS ALL RIGHTS RESERVED PRINTED IN U.S.A.
No. 908899 Tool Kit for Non-vented Rotors
Replaces Standard Cutting Tools.
1
1
Remove standard cutting tools
from model 6900 & 6950…
…by disconnecting
springs with the AMMCO
spring extractor.
2
2
Insert new cutting tools.
3
3
Reconnect Springs.
Insert brass plugs and
turn knobs IN.
Adjust guide screws for
smooth tool holder
movement.
Note: Under each lock
knob there is a brass
plug or brass gib.
Remove knobs &
plugs when replacing
tool holders.
