MIDI CONTROL MESSAGES
CHANNEL FADER, FX ON SWITCH
DB4
CHANNEL
FADER
1
CC 37
CH 16 E8
CH 16
2
CC 35
CH 16 F8
CH 16
3
CC 38
CH 16 F#8
CH 16
4
CC 36
CH 16 G8
CH 16
FX ON
CHANNEL FADER CURVE, XFADER CURVE, XFADER
CHANNEL FADER CURVE XFADER CURVE
G –1
CH 16
OFF
◄►
G#-1
CH 16
F#-1
CH 16
OFF
◄►
F –1
CH 16
CC 39
CH 16
XFADER
FILTERS
FILTER RES HPF BPF LPF FREQ ON
1(L)
CC 8
CH 16
B 6
CH 16
C 7
CH 16
C# 7
CH 16
CC 34
CH 16 D 7
CH 16
2(R)
CC 1
CH 16
C#-1
CH 16
D –1
CH 16
Eb-1
CH 16
CC 3
CH 16
E –1
CH 16
