Allen & Heath 15 ICE-16D User Guide
Mains Power Supply, Switch and Fuse
Standard IEC mains power inlet. The ICE-16D accepts mains voltages
from 90V to 265V at either 50Hz or 60Hz.
The On/Off switch powers the unit on or off.
The mains fuse is housed in the 20mm fuse holder
ICE-16D REAR PANEL FEATURES
Sync IN/OUT Connectors
8 pin mini DIN connectors. Use a 8 pin mini DIN cable to connect the
OUT of one ICE-16D unit to the IN of another. This allows two or
more ICE-16Ds to be synchronised together when recording multiple
tracks to more than one USB memory device.
IEEE1394 FireWire Ports
Standard 6 pin IEEE1394 device ports. You can connect either of these
to a host computer with FireWire in order to stream 16 channels of
digital audio to and from the ICE-16D. Two ICE-16Ds can be daisy-
chained together to double the number of channels on the FireWire
bus to 32..
USB 2.0 Device Port
Type B USB device port. An alternative connection to FireWire for
streaming 16 channels of digital audio to and from a computer.
Outputs
Balanced analogue outputs on 25pin D Sub-miniature connectors using
standard AES59 analogue pin configuration.
Inputs
Balanced analogue inputs on 25pin D Sub-miniature connectors using
standard AES59 analogue pin configuration.
