Page 22: Miscellaneous
22
icon
series
Faders, Potentiometers, Switches and Connectors:
Jumper Socket 2way
AL0334
1
Molex 0.1” Male 15 x 2 pin straight
AL3583
1
Speakon Connector NL4MP Chassis
AL8126
2
Jack Nut Slimline Plastic
AL8133
4
Fuse Clip Schurter
AL8134
5
Fuse Cover Schurter
AL8139
2
Common Semiconductors:
Transistor BC549 NPN
AE0020
15
IC TL072 Op-Amp
AE0046
4
IC Regulator 7815
AE0047
2
Transistor BC556B PNP
AE3001
5
Power Supply:
IC 4N35 Opto-Isolator (DL1000)
AE0266
-
IC Regulator 7805
AE0308
4
IC Comparator LM393N (DL1000)
AE2818
-
Diode BYV27-400 2A 400V (DL1000)
AE3469
-
Diode BYV26E 1A 1000V (DL1000)
AE3470
-
Diode P6KE200A (DL1000)
AE3471
-
Transistor Mosfet STP4NA80FI (DL1000)
AE3472
-
IC SMPS UC3842AN (DL1000)
AE3473
-
IC TL431 Voltage Reference (DL1000)
AE3475
-
Bridge Rectifier 2KBP06M (DL1000)
AE3477
-
Inrush Supressor 20R (DL1000)
AE3478
-
IC Regulator 7812 (DL1000)
AE3588
-
IC Regulator 7912 (DL1000)
AE3589
-
Inrush Supressor (DP1000)
AE8143
1
Mains Lead IEC-2pin Euro
AH0205
-
Mains Lead IEC-3pin UK
AH0206
-
Mains Lead IEC-3pin US (C33)
AH0323
-
Mains Fuse 20mm 5A A/Surge (DP1000)
AL2270
10
XLR 3 Pin Male 90deg PCB (DL1000)
AL2413
1
Fuse Holder 20mm PCB (DL1000)
AL3178
-
Mains Switch 10A PCB
AL3338
1
Fuse Holder 10A 20mm PCB (DP1000)
AL3447
1
Mains Fuse 20mm 10A A/Surge (DP1000)
AL3455
10
IEC Mains Inlet Filter PCB 3 Pin (DL1000)
AL3458
-
Mains Fuse 20mm 500mA A/Surge (DL1000) AL3534
10
Inductor 150uH 280mA (DL1000)
AM2970
-
Transformer DP1000 Toroid
AM3084
-
Inductor 4.7uH 600mA (DL1000)
AM3467
-
Transformer DL1000 Switch Mode
AM3476
-
Miscellaneous:
icon Packing Assembly
002-374
-
Insulating Kit TO220
AA0693
2
Rubber Keymat
AA3259
-
Flex cable 12way 90mm
AH2228
2
