Ordering an Assembly

The following assemblies are supplied fully tested. Please quote the description and order code for the
part required.

Printed Circuit Board (PCB) Assemblies:

Audio PCB assembly

002-379

Keypad PCB assembly

002-380

Fader PCB assembly

002-381

MIDI PCB assembly

002-382

Mains PCB assembly (DP1000 only)

002-384

Amplifier/Heat-sink PCB assembly (DP1000 only)

002-385

CPU/LCD PCB assembly

002-386

PSU PCB assembly

002-445

IDC connector harnesses:

DL/DP1000

16 way MIDI harness

AL3340

DL/DP1000

20 way Audio harness

AL3341

DL/DP1000

26 way Audio harness

AL3342

DL/DP1000

26 way Switch Mode PSU harness

AL3586
