ITG User’s Guide
Gateway B, 2 ports ITG, is configured as following:
1. Gateway B IP: 192.168.0.55, mask IP: 255.255.255.0, gateway IP 0.0.0.0 (virtual IP)
2. GW B ID=20
3. Port 0 of FXS has a telephone set connected, its phone number is 550
4. Port 1 of FXS has a telephone set connected, its phone number is 551
Gateway A and Gateway B dial plan setting
Gateway A address translation table
Address
Entry Hunt
Grp_Id
Min.
Digits
Max.
Digits
Prefix
strip
Prefix
Address
201 3 3 3 3 None
301 4 3 3 3 None
8 1 3 3 0 None
0 1 1 1 0 None
20 11 5 5 2 None
Gateway A hunt group table
Group id Type #Members Member ids
----------------------------------------------------------------------------
1 2 1 1
3 2 1 3
4 2 1 4
11 2 1 11
Gateway A destination table
Dest id Mode Destination
-------------------------------------------------------
1 Local PORT = 0
3 Local PORT = 2
4 Local PORT = 3
11 H.323 Dest = 192.168.0.55/1720 TCP
ITGB address translation table
Address
Entry Hunt
Grp_Id
Min.
Digits
Max.
Digits
Prefix
strip
Prefix
Address
550 1 3 3 3 None
551 2 3 3 3 None
10 11 5 5 2 None
ITGB hunt group table
Group id Type #Members Member ids
----------------------------------------------------------------------------
1 2 1 1
2 2 1 2
46 Command Line Interface
