ITG User’s Guide
Chapter 4 Configuring ITG from a Web Browser
This chapter explains procedures for configuring the ITG from the web browser.
4.1 Http setting mode
This section describes the processes for setting up Internet Telephony Gateway once it has been
installed. Microsoft Explorer version 4 or higher, or Navigator version 4.5 or higher can be used
in this section to view and change parameters.
PC Setup
In order to configure the ITG, PC needs to have TCP/IP protocol and a compatible IP Address.
1. Connect the ITG to network with a RJ-45 UTP cable. Power it on.
2. Find a PC, for example, Windows 95/98. Under Windows 95/98, select the Network
Neighborhood icon on the desktop, then select Properties. We will see a screen like below:
3. If a line like the one highlighted ("TCP/IP -> Network Card”) is not listed , select Add-
Protocol-Microsoft-TCP/IP-OK to add it.
4. Select Properties for the “TCP / IP -> Network card” entry. You will see a screen like the
following:
5. On the IP Address table, enter values as follows:
18 Configuring ITG from a Web Browser
