2N VoiceBlue Next v3.6 User Manual

Page 53

Generate virtual ring tone – enable/disable generation of the virtual ringing tone
to the VoIP interface.
Call length counting: select whether the call should be counted in seconds or
minutes.
BTS lock – identify the BTS to which the GSM modules should be logged fixedly.
Restart the selected GSM modules to execute the changes.

Network operator code (MCC+MNC) – set the local mobile network provider code
manually. If you do not enter a value, the provider will be selected automatically.
After call relax delay – interval between the current call termination and next call
setup via the same GSM/UMTS module. 2 seconds is recommended for
high-traffic installations.

Disconnect call

Specify the reasons for an immediate disconnection of an outgoing GSM/UMTS call.

Send CLIP from VoIP to GSM/UMTS

Transfer CLIP to GSM/UMTS – enable/disable the function.
Separating char – the CDN/CLIP separating character.
Modify (" removes one digit) – you can change the CLIP. The "– character is used
for deleting one char from the left.

GPRS activation

APN string

define the Access Point Name (APN) for GPRS connectivity.

–

Basic settings

Roaming enabled for network code – set the international network identifier for
roaming purposes consisting of the following two codes:

MCC – Mobile Country Code – country code (Czech Republic – 230);
MNC – Mobile Network Code – GSM code (T-Mobile – 01, 0202, Vodafone –
03).

Hence, the international identification code for T-Mobile CZ is 23001. Leave this field
empty to disable roaming.

Caution

The BTS lock service works with specific GSM modules only (Q55)!
An error in BTS identification results in a GSM module login failure.

Caution

The

service must be supported by the

Send CLIP from VoIP to GSM

GSM/UMTS provider. If not, the provider's network may reject the call!
