Advantages of use – 2N Helios IP Video Kit User Manual

Page 5

Helios IP Video Kit is equipped with two galvanically isolated digital inputs and

three status signalling outputs.

Helios IP Video Kit is very easy to install. All you have to do is connect it to

your LAN using the LAN cable. An integrated two-port LAN switch simplifies installation
on sites with a limited LAN infrastructure. Supply the intercom either from a 9–36 V
source or directly from your POE supporting LAN.

Use a PC web browser to configure your

. Apply the

Helios IP Video Kit

to administer extensive intercom installations easily and quickly.

Manager

Advantages of Use

Industrial design and variable mounting options
Wide supply power range + PoE supply
Two analog cameras connection
Integrated 10 W power amplifier
External amplifier connection
External microphone/audio signal source connection
Galvanically isolated relay output
Two controlled active 12 V outputs
Two galvanically isolated logic inputs
Up to 3 signalling LED outputs
Up to 16 external buttons/matrix keypad connection
Integrated two-port LAN switch
Bidirectional communication – acoustic echo cancelling
Configuration via web interface/special PC application
SIP 2.0 support
HTTP(S) server for configuration
SNTP client for server time synchronisation
RTSP server for audio streaming
TFTP client for automatic configuration and firmware update
