4 LOG SPLITTER
SAFETY
5
2
3 6
1
4
1.7 saFeTY DeCal loCaTIons
1
Pn 12174
TuRN ENgINE
OFF BEFORE
S E R V I C I N g
MACHINE. KEEP
All BODy PARTS
ClEAR OF THE
SPlITTINg AREA
WHIlE SPlITTINg WEDgE IS IN MOTION.
THE HyDRAulIC CylINDER AND SPlITTINg
WEDgE CAN CAuSE SEVERE BODIly HARM.
BEFORE OPERATINg lOg SPlITTER, CONSulT
OWNERS MANuAl FOR PROPER OPERATION
AND MAINTENANCE TECHNIQuE.
PN 12174
3 Pn 18983-00
2
Pn 14942-00
5
6
4
Pn 32345-00
Pn 36090-00
Pn 32158-00
READ AND uNDERSTAND yOu OWNERS MANuAl BEFORE
OPERATINg. IF OWNERS MANuAl WAS NOT INCluDED OR
yOu HAVE ANy QuESTIONS, PlEASE CAll 800.247.7335 OR
701.282.5520 (u.S.A.)
FEED ROllER SuPPORT MuST BE
SECuRED IN THE uP POSITION PRIOR
TO SERVICINg CHIPPER FEED AREA.
THE FEED ROllER CAN FAll AND
CAuSE SEVERE BODIly HARM. CONSulT OWNERS MANuAl FOR
PROPER METHOD OF SECuRINg FEED ROllER SuPPORT. lOWER
FEED ROllER BEFORE OPERATINg CHIPPER.
265 585
4.80-8 410 kPa, 60 psi
Familiarize yourself with all of the safety and operational decals on the machine and the associated hazards. See the
engine owner’s manual or contact the engine manufacturer for engine safety instructions and decals. Make certain that
all safety and operating decals on this machine are kept clean and in good condition. Decals that need replacement
must be applied to their original locations.
DO NOT OPERATE MACHINE WITHOuT
SHIElDS IN PlACE. FAIluRE TO DO SO MAy
CAuSE SERIOuS INJuRy OR DEATH.
Model lS27 shown
