Features & controls, 1 dl12670 (75124) controls – Echo DL10570 Owners Manual v.1 User Manual
Page 14
Debris Loader Owner’s Manual
10
DISCHARGE TUBE
DISCHARGE TUBE
HANDLE
HOSE
SUPPORT
HOSE HANDLE
FUEL
TANK
BATTERY BOX
ENGAGEMENT
LEVER
BELT SHIELD
HOSE
HOLDER
MANUAL
HOLDER
SAFETY CHAINS
HITCH JACK
Section
3
FEATURES & CONTROLS
3.1 DL12670 (75124) CONTROLS
Figure 7, DL12670 (75124) controls
AVAILABLE KITS
KIT
PART NUMBER
CHUTE EXTENSION KIT
75888-00
