5" and 8" Skid Steer Chipper Owner's Manual 21
section
7
specifications
model 74500 & 74800 dimensional daTa
model a b c d e f g h i
74500 91.9 102.2 56.4 46.0 48.1 49.2 23.3 29.6 6.0
74800 92.2 103.3 59.6 46.0 45.4 56.5 23.6 37.8 8.0
sPecificaTions
rOtOr SPeed 2000 rPM at 15 gPM 1500 rPM at 25 gPM
FraMe Material 1/4" tHiCk Steel CONStruCtiON 1/4" tHiCk Steel CONStruCtiON
CHute Size 32" x 36" 32" x 36"
drive SySteM HydrauliCS HydrauliCS
Skid-Steer HydrauliCS StaNdard Or HigH-FlOW HigH-FlOW
CHiPPer BladeS 4 BladeS (tOOl Steel) 4 BladeS (tOOl Steel)
rOtOr Size 20" x 1-1/4", 140 POuNdS 30" x 1-1/4", 275 POuNdS
WeigHt 1145 lBS. 1525 lBS.
CHiPPer OPeNiNg Size* 5-1/2" x 7" 9" x 9"
CONtiNuOuS CHiPPiNg Size* 3" (76.2 MM) diaMeter 5" (127 MM) diaMeter
diSCHarge tuBe rOtatiNg aNgle raNge 360 degreeS 360 degreeS
*CONtiNuOuS CHiPPiNg Size ratiNg reFerS tO tHe SuggeSted FeediNg Size OF liMBS FOr NOrMal OPeratiONS.
liMBS uP tO tHe CHiPPer OPeNiNg Size May Be Fed, But deCreaSed PerFOrMaNCe Will OCCur.
"H"
"A"
"I"
"C"
"E"
"F" "B"
"D"
"G"
7.1 size sPecificaTions
