Page 25 4.5" BearCat Chipper Operator's Manual
7.1 SIZE SPECIFICATIONS
Section
Specifications
7
Specifications are subject to change due to design modifications.
68" x 43" x 41-1/2" (77412)
68" x 57" x 53" (77412S)
Max. Chipper Capacity (Dia.) 4-1/2"
Chipper Blade Qty.
2 reversible
(3/8" x 5-3/32" x 4")
Rotor Size 14" Dia. X 1"
Rotor Weight (w/blades)
49 lbs.
(45 lbs. w/out blades)
4.5" x 9" (standard)
4.5" x 4.5" (optional)
Drive Type Belt
Belt Size 2RB61 Armid Construction
400 lbs. (77412)
448 lbs. (77412S)
Wheel Base Adjustable 35" to 46"
Tires 480/400 x 8 Pneumatic
Fuel Tank Capacity (gal.) 4 qts. w/shutoff valve
Engine
12 HP B&S Electric Start Intek
(gasoline)
Specifications (77412, 77412S)
Weight (lbs.)
Overall Size
Discharge Size
76" x 43.5" x 46" (77413)
76" x 57.5" x 58" (77413S)
Max. Chipper Capacity (Dia.) 4-1/2"
Chipper Blade Qty.
2 reversible
(3/8" x 5-3/32" x 4")
Rotor Size 14" Dia. X 1"
Rotor Weight (w/blades)
49 lbs.
(45 lbs. w/out blades)
4.5" x 9" (standard)
4.5" x 4.5" (optional)
Drive Type Belt
Belt Size 2RB61 Armid Construction
450 lbs. (77413)
498 lbs. (77413S)
Wheel Base 44"
Tires 4.80-8 Load Rating B
Fuel Tank Capacity (gal.) 1.72 gallons
Engine
Honda OHV 13 HP
(gasoline)
Specifications (77413, 77413S)
Overall Size
Weight (lbs.)
Discharge Size
