4 INCH CHIPPER
20
TROUBLESHOOTING
Section
SpECIFICaTIoNS
7
7.1 CHIppER SpECIFICaTIoNS
Rotor will not turn.
drive belt too loose or broken.
Replace belt or spring.
obstructed discharge.
use branch or similar object to clear discharge.
plugged rotor.
Clear rotor. Feed material more evenly.
Cannot engage clutch.
Improper belt installation; belt
not under belt guide.
Install belt properly; install belt under belt guide.
Improper belt tension.
Adjust belt tension. Replace belt or spring if needed.
Excessive belt wear.
not using correct belt.
Contact your nearest authorized dealer to order the correct belt for
your chipper/shredder.
Pulley(s) damaged or worn.
Replace pulley(s).
Pulley(s) not in alignment.
Align pulley(s) with straight edge.
Belt(s) tension too loose.
Replace belt or spring.
Trailer sways during
towing.
tire air pressure not correct
Check tire sidewall for inflation limits.
CH4614 (73420)
dESCRIpTIoN
English
metric
OVERAll SIZE
73" x 52" x 87"
185.4 x 132.1 x
221.0 cm
OVERAll WEIgHT
820 lbs
372.7 kg
MAX CHIPPER CAPACITy
4"
10 cm
CHIPPER BlADES
4 Reversible tool
Steel
4 Reversible tool
Steel
CHIPPINg ANVIl
5.63" X 4.00" X
0.375"
14.3 cm x 10.2 cm
x 0.95 cm
DISC SPEED
1825 RpM
1825 RpM
DISC SIZE
20" x 1.25"
50.8 cm x 3.2 cm
DISC WEIgHT
140 lbs.
63.6 kg
DISCHARgE TuBE SIZE
6"
15.25 cm
DRIVE TyPE
BElT
BElT
DRIVE BElT SIZE
2B70
2B70
TIRE SIZE
5.30-12
5.30-12
ENgINE
honda 630cc
honda 630cc
FuEl TANk CAPACITy
6.6 gal.
25 liters
CH4540 (73454)
dESCRIpTIoN
English
metric
OVERAll SIZE
48" x 45" x 87"
122.0 x 114.3 x
221.0 cm
OVERAll WEIgHT
600 lbs.
272.7 kg
MAX CHIPPER CAPACITy
4"
10 cm
CHIPPER BlADES
4 Reversible tool
Steel
4 Reversible tool
Steel
CHIPPINg ANVIl
5.63" X 4.00" X
0.375"
14.3 cm x 10.2 cm
x 0.95 cm
DISC SPEED
1650 RpM
1650 RpM
DISC SIZE
20" x 1.25"
50.8 cm x 3.2 cm
DISC WEIgHT
140 lbs
63.6 kg
DISCHARgE TuBE SIZE
6"
15.25 cm
DRIVE TyPE
BElT
BElT
DRIVE BElT SIZE
BX56 (2)
BX56 (2)
pto
540 +/- 10 RPM 540 +/- 10 RPM
