background image

26

6 INCH CHIPPER

SPECIFICATIONS

CoNTRoL LIGHT FLaSH CoDES

SIGNaL

FREQuENCY

CauSE

aCTIoN To TaKE

Green

Solid

Forward feed available.

Begin feeding materials into the

chute.

Green

One flash per second

RPM not high enough to chip upon

initial startup.

Increase RPM until the green

light stops flashing.

Green

One flash per second

RPM dropped suddenly or fell below

preset range (due to obstruction).

No action necessary, the feed

roller will automatically be

reversed.

Red

One flash per second

Feed bar is not in Stop (upon

initial startup or when RPM has

dropped).

Put feed bar in Stop position.

Red

Solid

(European models only). light is

solid red upon startup.

Push reset/override button to

reset.

(European models only). Safety bar

was activated.

(Domestic models only). Jumper

harness plug was damaged.

Check connections to jumper

harness plug. Replace if plug

necessary (PN 36391-00)

Amber

long and short flashes at initial

startup

When the controller is started up,

it will flash an amber code to show

total hours of operation. Each long

flash equals 10 hours of operation,

each short flash equals 1 hour of

operation.

No action necessary. The

hours of operation code can

be interrupted by engaging the

feed roller.

Amber

Two flashes followed by a 1.5

second pause and then two

flashes followed by a long

pause

Chipper blades should be checked

and sharpened if necessary.

Check sharpness of chipper

blades. Reset the controller

by shifting the feed bar from

stop to reverse and back three

times within 8 seconds after the

machine is started.

Amber

Three flashes followed by a

1.5 second pause and then

three flashes followed by a long

pause

Engine oil should be changed.

Change oil. to reset the

controller, turn on power to the

machine, wait 10 seconds, then

shift the feed bar from stop to

reverse and back three times

within 8 seconds.

Amber

Two flashes followed by a 1.5

second pause and then five

flashes followed by a long

pause

Forward feed has a short or open

circuit.

Check connections to the

forward coil on the feed

hydraulic valve. Replace coil if

necessary.

Amber

Two flashes followed by a

1.5 second pause and then

six flashes followed by a long

pause

Reverse feed has a short or open

circuit.

Check connections to the

reverse coil on the feed

hydraulic valve. Replace coil if

necessary.

7.4 FLaSH CoDES FoR THE CoNTRoL LIGHT
