9 INCH CHIPPER
21
ENGLISH
TROUBLESHOOTING
7.1 CHIPPER SPECIFICATIoNS
SPECIFICATIoNS
7
Section
Rotor will not turn.
Drive belt too loose or broken.
Replace belt or spring.
Obstructed discharge.
use branch or similar object to clear discharge.
Plugged rotor.
Clear rotor. Feed material more evenly.
Cannot engage clutch.
Improper belt installation; belt not
under belt guide.
Install belt properly; install belt under belt guide.
Improper belt tension.
Adjust belt tension. Replace belt or spring if needed.
Excessive belt wear.
Not using correct belt.
Contact your nearest authorized dealer to order the correct belt for
your chipper/shredder.
Pulley(s) damaged or worn.
Replace pulley(s).
Pulley(s) not in alignment.
Align pulley(s) with straight edge.
Belt(s) tension too loose.
Replace belt or spring.
Trailer sways during
towing.
Tire air pressure not correct
Check tire sidewall for inflation limits.
CH911DH (72928)
DESCRIPTIoN
English
metric
OVERALL SIzE
119" x 79" x 89"
302 X 201 X 226 cm
OVERALL
WEIgHT
2480 lbs.
1126 kg
MAX CHIPPER
CAPACITY
9"
23 cm
CHIPPER BlADES 4 Reversible Tool
Steel
4 Reversible Tool Steel
CHIPPINg ANVIl
9.1" x 4.0" x 0.6"
23.1 x 10.2 x 1.5cm
DISC SPEED
1500 RPM
1500 RPM
DISC SIzE
30" dia. x 1.25"
76 cm x 3.18 cm
DISC WEIgHT
275 lbs.
125 kg
DISCHARgE
TUBE SIzE
8"
12.7 cm
DRIVE TYPE
Belt
Belt
DRIVE BELT SIzE
3B83
3B83
HyDRAulIC BElT
SIzE
BX38
BX38
TIRE SIzE
P215/70R15
P215/70R15
JACK
850 lb. rating
385 kg
ENgINE
1.1 L Diesel
1.1 L Diesel
FUEL TANK
CAPACITY
18 gal.
68 L
HyDRAulIC
FEED RATE
6.6 gal/min
25 L/min
HyDRAulIC OIl
TANK CAPACITY
3 gal
11.4 L
CH922DH (74950)
DESCRIPTIoN
English
metric
OVERALL SIzE
119" x 79" x 89"
302 X 201 X 226 cm
OVERAll WEIgHT
2700 lbs.
1226 kg
MAX CHIPPER
CAPACITY
9"
23 cm
CHIPPER BlADES
4 Reversible Tool
Steel
4 Reversible Tool
Steel
CHIPPINg ANVIl
9.1" x 4.0" x 0.6"
23.1 x 10.2 x 1.5cm
DISC SPEED
1500 RPM
1500 RPM
DISC SIzE
30" dia. x 1.25"
76 cm x 3.18 cm
DISC WEIgHT
275 lbs.
125 kg
DISCHARgE TuBE
SIzE
8"
12.7 cm
DRIVE TYPE
Belt
Belt
DRIVE BELT SIzE
3RBP90
3RBP90
HyDRAulIC BElT
SIzE
BX38
BX38
TIRE SIzE
P215/70R15
P215/70R15
JACK
850 lb. rating
385 kg
ENgINE
2.2 L Diesel
2.2 L Diesel
FUEL TANK
CAPACITY
18 gal.
68 L
HyDRAulIC FEED
RATE
6.6 gal/min
25 L/min
HyDRAulIC OIl
TANK CAPACITY
3 gal
11.4 L
