SECTION 1 - SPECIFICATIONS
3121139 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS 1.2 SPECIFICATIONS AND PERFORMANCE
DATA
Table 1-1. Operating Specifications
Maximum Work Load (Capacity)
Unrestricted:
Restricted
500 lb (230 kg)
Refer to Capacity Decals on
machine for restricted platform
capacities
Maximum Capacity - Dual Rating
800S
860SJ
1000 lb. (450 kg)
750 lb. (340 kg)
Maximum Travel Grade (Gradeability)*
2WD
4WD
30%
45%
Maximum Travel Grade (Side Slope)* 5°
Maximum Vertical Platform Height: 800S - 80 ft. (24.3 m)
860SJ - 86 ft. (26.2 m)
Maximum Horizontal Platform Reach
800S
860SJ
71 ft. (21.6 m)
75 ft. (22.9 m)
Turning Radius (outside) 22 ft. 6 in. (6.8 m)
Turning Radius (inside) 12 ft. (3.6 m)
Maximum Drive Speed: 3.5 mph (1.5 m/s)
Max. Hydraulic System Pressure 4500 psi (310 Bar)
Maximum Wind Speed 28 mph (12.5 m/s)
Maximum Manual Force 400 N
Electrical System Voltage 12 Volts
Gross Machine Weight (Platform Empty)
800S
860SJ 34,700 lbs. (15,740 kg)
37,900 lbs. (17,191 kg)
* With boom in stowed position
Table 1-2. Specifications and Performance Data
Swing 360°
Tail Swing 4’8" (1.42 m)
Platforms 36" x 72" (0.91m x 1.83m)
36" x 96" (0.91m x 2.44m)
Overall Width 8’ 2" (2.5 m)
Stowed Height
800S
860SJ
9’ 10.6" (3.01 m)
10’ (3.04 m)
Stowed Length
800S
860SJ
37’ 3.25" (11.4 m)
40’ (12.2 m)
Wheel base 10’ (3.04 m)
Ground Clearance 15.625" (0.4 m)
Drive Speed
Stowed 2WD
Stowed 4WD
Elevated
3.0 mph (5.5 kph)
3.5 mph (5.6 kph)
0.75 mph (1.2 kph)
Ground Bearing Pressure - 800S
15-625
15-625FF
41/18LLx22.5
72 psi (5.0 kgm/cm 2 )
79 psi (5.5 kgm/cm 2 )
68 psi (4.8 kgm/cm 2 )
Ground Bearing Pressure - 860SJ
15-625
15-625FF
41/18LLx22.5
81 psi (5.7 kgm/cm 2 )
92 psi (6.5 kgm/cm 2 )
79 psi (5.5 kgm/cm 2 )
Max. Tire Load - 800S
15-625
15-625FF
41/18LLx22.5
16,900 lbs. (7665 kg)
17,200 lbs. (7802 kg)
17,300 lbs. (7850 kg)
Max. Tire Load - 860SJ
15-625
15-625FF
41/18LLx22.5
19,800 lbs. (8981 kg)
20,100 lbs. (9117 kg)
20,200 lbs. (9163 kg)
