SECTION 5 - GENERAL SPECIFICATIONS AND MAINTENANCE
5-4 – JLG Lift – 3121684
Machine Dimensional Data Tires
Batteries
Table 5-3. Dimensions
DESCRIPTION R6
Platform Height - Elevated
(Ground to Platform Floor)
5.79 m (19 ft)
Platform Height - Stowed
(Ground to Platform Floor)
100 cm (39.5 in.)
Working Height 7.47 m (24 ft. 6 in.)
Rail Height
(Platform Floor to Top of Rail)
101.6 cm (40 in.)
Overall Machine Width 81.2 cm (32 in.)
Overall Machine Length (w/ladder) 2.08 m (81.8 in.)
Platform Size - Length 1.82 m (71.3 in.)
Platform Size - Width 68.9 cm (27.1 in.)
Wheelbase 139.7 cm (55 in.)
Table 5-4. Tire Specifications
DESCRIPTION R6
Size 323 mm x 100 mm
(12.71 in. x 3.94 in.)
Wheel Bolt Torque 163 Nm (120 ft lb.)
Table 5-5. Battery Specifications
DESCRIPTION R6
Voltage (24V System - Series) 6 V per battery
Amp Hour (Standard Battery) 220 Amp Hour @ 20 HR. Rate
Reserve Capacity (Standard Battery) 447 Minutes
