SECTION 5 - GENERAL SPECIFICATIONS AND MAINTENANCE
5-2 – JLG Lift – 3121684
5.2 OPERATING SPECIFICATIONS
Table 5-1. Operating Specifications
DESCRIPTION R6
PLATFORM
Maximum Platform Height 5.79 m (19 ft.)
DRIVING
Maximum Drive Speed Stowed:
Elevated:
4.0 kph (2.5 mph)
0.8 kph (0.5 mph)
Maximum Stowed Travel Grade (Gradeability)
(Reference Figure 3-9. on page 3-16)
25% (14°)
Inside Turning Radius 0.6 m (23.6 in.)
Outside Turning Radius 2.22 m (87.9 in.)
CHASSIS
Approximate Gross Machine Weight 1,588 kg (3,500 lb.)
Maximum Tire Load (per wheel) 620 kg (1,365 lb.)
Ground Bearing Pressure 9.18 kg/cm
2
(130 PSI)
Ground Clearance (Pot-Hole Stowed - Center)) 95.5 mm (3.75 in.)
Wheelbase 1397 mm (55 in.)
Maximum Hydraulic Pressure Main/Lift Relief:
Steer Relief:
159 bar (2300 psi)
69 bar (1000 psi)
