SECTION 1 - SPECIFICATIONS
3121201 – JLG Lift – 1-5
1.6 LUBRICATION
Hydraulic Oil
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficient
chemical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobilfluid 424
hydraulic oil, which has an SAE viscosity index of
152.
NOTE: When temperatures remain below 20° F (-7 degrees
C), JLG Industries recommends the use of Mobil
DTE 13M.
Aside from JLG recommendations, it is not advisable to
mix oils of different brands or types, as they may not con-
tain the same required additives or be of comparable vis-
cosities. If use of hydraulic oil other than Kendall Hyken
052 or Mobilfluid 424 is desired, contact JLG Industries for
proper recommendations.
1.7 PRESSURE SETTINGS
1.8 CYLINDER SPECIFICATIONS
Table 1-16. Hydraulic Oil
HYDRAULIC SYSTEM OPERATING
TEMPERATURE RANGE
SAE VISCOSITY
GRADE
+0° to +180° F (-18° C to +83° C) 10W
+0° F to +210° F (-18° C to +99° C) 10W-20, 10W-30
+50° F to +210° F (+10° C to +210° C) 20W-20
Table 1-18. Mobil DTE 13M Specs
ISO Viscosity Grade #32
Specific Gravity 0.877
Pour Point, Max -40°F (-40°C)
Flash Point, Min. 330°F (166°C)
Viscosity
at 40° C 33cSt
at 100° C 6.6 cSt
at 100° F 169 SUS
at 210° F 48 SUS
cp at -20° F 6,200
Viscosity Index 140
Table 1-17. Mobilfluid 424 Specs
SAE Grade 10W30
Gravity, API 29.0
Density, Lb/Gal. 60°F 7.35
Pour Point, Max -46°F (-43°C)
Flash Point, Min. 442°F (228°C)
Viscosity
Brookfield, cP at -18°C 2700
at 40° C 55 cSt
at 100° C 9.3 cSt
Viscosity Index 152
Table 1-19. Pressure Settings
Main Relief 3000 PSI (206.85 Bar)
Upper Boom Lift Down 1200 PSI (83 Bar)
Swing 1700 PSI (117.2 Bar)
Platform Level Forward 2800 PSI (193 Bar)
Platform Level Backward 1800 PSI (124 Bar)
Steer 1800 PSI (124 Bar)
Steer Reliefs - 4WS Front & Rear 2500 PSI (172 Bar)
Articulating Jib Boom Up 1500 PSI (103 Bar)
Articulating Jib Boom Down 1200 PSI (83 Bar)
Table 1-20. Cylinder Specifications - 600A
DESCRIPTON BORE STROKE ROD DIA.
Lower Lift 6.5
(165.1)
34.0625
(865.2)
2.5
(63.5)
Tower Telescope 3
(76.2)
63.75
(1619.3)
2
(50.8)
Upright Level 6
(152.4)
34.625
(879.5)
3
(76.2)
Upper Lift 4
(101.6)
36.625
(930.3)
2.5
(63.5)
Upper Telescope 3
(76.2)
177.75
(4514.9)
2
(50.8)
Steer (2WD/
2WS) 2.5
(63.5)
8.812
(204.7)
1.25
(31.8)
Steer (4WD/
2WS) 2.5
(63.5)
10.75
(273.1)
1.25
(31.8)
Lockout (2WD) 3.5
(88.9)
3.875
(98.4)
2.5
(63.5)
Lockout (4WD 3.5
(88.9)
3.875
(98.4)
2.5
(63.5)
Master 3
(76.2)
8.5
(215.9)
1.5
(38.1)
Slave 3
(76.2)
8.5
(215.9)
1.5
(38.1)
