SECTION 1 - SPECIFICATIONS
3121201 – JLG Lift – 1-3
Tires
Drive System
Swing System
Pumps
Hydraulic Filters
Dimensional Data
Table 1-8. Tire Specifications
Size 14 x 17.5 14 x 17.5 14 x 17.5 IN355/
55D625
IN355/
55D625
18x625
Load Range G G * G G H
Ply Rating 14 14 N/A 14 14 16
Tire Pres-
sure 90 PSI
(6 Bar)
Foam-
Filled
Air-Boss 90 PSI
(6 Bar)
90 PSI
(6 Bar)
75 PSI
(5.2 Bar)
* Load Capacity - 11,800 lb. (5353 kg) -
Static
Table 1-9. Drive System
Drive Motor Displacement 2.8 cu. in. max. 1.1 cu. in. min.(46
cm3] max. 18 cm3] min.)
Drive Hub Ratio 39.96:1
Drive Brake Automatic spring applied,
hydraulically released disc brakes
Table 1-10. Swing System
Swing Motor Displacement 4.62 cu. in. (75 cm3])
Swing Brake Automatic spring applied
hydraulically released disc brakes
Swing Hub Ratio 50:1
Hydraulic Gear Pump @ 1800
RPM 7.9 GPM (29.90 lpm)
Pump Displacement
1.02 cu. in. (16 cm 3 )
Rotation Clockwise
Table 1-11. Pumps
Hydraulic Gear Pump
Output @ 1800 RPM
7.9 GPM (29.90 lpm)
Displacement
1.02 cu. in. (16 cm
3
)
Rotation Clockwise
Auxiliary Power Pump
Output
2.6 gpm 1200 psi
(9.8 lpm @82.7 BAR)
Pump Displacement
0.244 cu. in. (14 cm
3
)
Motor Type DC
Rotation Clockwise
Table 1-12. Pumps
Return - Bypass Type 10 Microns Absolute
Charge 10 Microns Absolute
Hydraulic Strainers (In Tank) 30 Microns
Table 1-13. Dimensional Data
Machine Height (Stowed) 8 ft. 3.75 in. (2.53 m)
Machine Length (Stowed)
600A Over Drive Axle
600AJ Over Drive Axle
26 ft. 5 in. (8.05 m)
28 ft. 11.4375 in. (8.82 m)
Machine Width
Standard
Narrow Chassis
8 ft. (2.44 m)
7 ft. (2.13 m)
Wheelbase 8 ft. 0 in. (2.44 m)
Boom Elevation - 600A +60 ft. 5 3/8 in. (18.42 m)
-11 in. (0.28 m)
Boom Elevation - 600AJ +60 ft. 6 3/4 in. (18.46 m)
-2 ft. 8 13/16 in. (0.83 m)
