3-22 3120885
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
41 Counterbalance Valve Assembly Options: 1
Use 7017172 Helac p/n 24327 Stamped beside Mounting
Screws (was p/n 7017125)
7017172 Helac p/n 26553 or 26554 Stamped beside Mount-
ing Screws
41A Valve, Cartridge Options: A/R
7011323 Valve, Cartridge for Helac p/n 24327 Valve 2
2900770 Seal Kit - 7011323 Cartridge (1 Per Assem-
bly) 2
7017192 Valve, Cartridge Helac p/n 26553 (No Seal Kit
Available) 2
42 Not Available Bushing, Shaft 2
43 to 50 Not Used
— — — — — — — — — —
51 Bearing Kit Options (Includes Items 32 - 34): 1
7017122 0060044 & 0060052 Rotators
7017134 0060046 Rotator
52 Seal Kit Options (Includes Items 20,22,24,25,26 &
27): 1
0060044 & 0060052 Rotators Options:
7017127 Standard
70000341 Low Temperature
0060046 Rotator Options:
7017165 Standard (was p/n 7017133)
Not Available Low Temperature
53 Hardware Kit Options: 1
7017123 0060044 & 0060052 Rotators
7017132 0060046 Rotator
FIGURE 3-8. ROTATOR ASSEMBLY (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
