SECTION 1 FRAME
FIGURE 1-4. HYDRAULIC COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0257816 HYDRAULIC MOTOR/PUMP/TANK INSTALLATION Ref. 4/C
1 3600289 Motor/Pump Assembly 1
1A 7021318 Motor Assembly 1
7021368 Brush Kit 1
1B 7021319 Pump Assembly 1
Not Available Seal Kit 1
1C 7021367 Coupling 1
2 4400416 Hydraulic Tank Assembly 1
2A 7021320 Cap 1
3 3571160 Plate, Mounting 1
4 4711400 Flatwasher 1/4” Narrow 4
5 3311405 Locknut 1/4”-20NC 4
6 0741506 Screw, Flathead Countersink 5/16”-18NC x 3/4” 4
7 4751500 Flatwasher 5/16” 4
8 3311505 Locknut 5/16”-18NC 4
9 3311605 Locknut 3/8”-16NC 2
10 4751600 Flatwasher 3/8” 2
11 4761400 Lockwasher 1/4” 4
12 4761600 Lockwasher 3/8” 2
VALVES INSTALLATIONS
0258034 E45A & M45A Ref. 4/C
0259399 E45AJ & M45AJ Ref. 3/B
0259951 E40AJP, M40AJP, E40AJPnarrow & M40AJPnarrow Ref. 3/A
101 to 107 Not Used
108 0641608 Bolt 3/8”-16NC x 1” 2
109 4711600 Flatwasher 3/8” 2
110 4761600 Lockwasher 3/8” 2
111 to 113 Not Used
114 Brake/Steer Control Valve Assembly Options: 1
Use 4641149 Prior to S/N 47551 (was p/n 4641071)
Use 4641149 S/N47551 to S/N50960 (was p/n 464113)
4641149 S/N50960 to Present (See Figure 1-5 for
Breakdown)
115 to 119 Not Used
120 Harness Assembly - Brake/Steer Control Valve
Options: (Not Shown -See Section 7 for Breakdown) 1
4922069 Prior to S/N 47551
4922328 S/N47551 to Present
