FIGURE 5-3. PLATFORM LEVEL CYLINDER ASSEMBLY (AJ & AJP)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLY Ref
1683760 E45AJ & M45AJ Ref B
1683924 E40AJP & M40AJP Ref B
1 0100011 Loctite #242 A/R
2 0100038 Primer, Locking #7471 A/R
3 3931016 Bolt, Socket Head #10-24NC x 1” 3
4 Tapered Bushing Options: 1
0961900 E45AJ & M45AJ
0962185 E40AJP & M40AJP
5 0961951 Bushing, Garmax 4
6 Head Options: 1
1683052 E45AJ & M45AJ
1683925 E40AJP & M40AJP
7 1683759 Rod 1
8 1683761 Barrel 1
9 3760368 Washer, Ring 1
10 Piston Options: 1
3480247 E45AJ & M45AJ
3480259 E40AJP & M40AJP
11 Not Used
12 Kit Ring, Lock 2
13 Kit Ring, Wear 1
14 Kit Ring, Back-Up 2
15 Kit O-Ring 1
16 Kit O-Ring 1
17 Kit Wiper 1
18 Kit Seal 1
19 Kit Ring, Back-Up 1
20 Kit Seal 2
21 4640932 Cartridge, Valve (Counterbalance Vented) 1
7011112 Seal Kit-4640932 Valve 1
22 4641086 Cartridge, Valve (Counterbalance Non Vented) 1
2900792 Seal Kit-4641086 Valve 1
23 3931516 Bolt, Socket Head 5/16”-18NC x 1” 8
— — — — — — — — — —
Seal Kit Options: (Includes Items 12-20) 1
2901776 E45AJ & M45AJ
2901898 E40AJP & M40AJP
