SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODELS E45/M45/E40 & M40
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further infomation, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
3990105
Sensor, Speed (Figure 1-2)
1
1
1
7021367
Coupling, Pump (Figure 1-4)
1
1
1
7021320
Cap, Breather (Figure 1-4)
1
1
1
7021618
Coil (Figure 1-5)
1
1
1
7021609
Coil (Figure 1-5, 2-1 & 2-2)
1
1
1
7021616
Filter Cartridge (Figure 1-5)
1
1
1
7020654
Relay (Clear) (Figure 1-8)
1
1
1
7020691
Fuse DC-50 Amp (Figure 1-8)
1
1
1
1600293
Module, Posi-Track/Tilt (Figure 1-9)
1
1
1
1600292
Module, Power (Figure 1-9)
1
1
1
7022002
Contactor (Figure 1-9)
1
1
1
7022001
Contactor (Figure 1-9)
1
1
1
7022000
Contactor (Figure 1-9)
1
1
1
7021610
Coil (Figure 2-2)
1
1
1
4360476
Contact, Switch Block (Figures 2-7 & 4-3)
1
1
1
4360328
Switch, Toggle (Figures 2-7 & 4-3)
1
1
1
4360475
Switch, Mushroom (Figures 2-7 & 4-3)
1
1
1
4360470
Switch, Key (Figure 2-7)
1
1
1
2860030
Key, Replacement (Figure 2-7)
1
1
1
4360070
Breaker, Circuit (Figure 2-7)
1
1
1
4360321
Switch, Limit (Figure 3-9)
1
1
1
4360031
Footswitch (Figure 4-1)
1
1
1
1001118419
Controller (Lift and Swing) (Figure 4-3)
1
1
1
1001118418
Controller (Drive and Steer) (Figure 4-3)
1
1
1
4360462
Controller, Speed (Figure 4-3)
1
1
1
4360387
Switch, Push Button (Figure 4-3)
1
1
1
0610128
Module, Platform Console (Figure 4-3)
1
1
1
4360330
Switch, Toggle (Figure 4-3)
1
1
1
4360448
Breaker, Circuit (Figure 4-3)
1
1
1
7003982
Switch, Steer (Drive and Steer) (Figure 4-5)
1
1
1
3990001
Diode (Figure 7-4)
2
2
2
2900838
U.S. Standards Fastener (Hardware) Kit
1
1
1
7014676
U.S. Standards Tool Kit
1
1
1
