3-4
3120885
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
11
Pin Options:
3
3422175
E45 & M45
3422481
E40 & M40
12
Pin Options:
2
3422176
E45 & M45
3422845
E40 & M40
13
Pin Options:
9
3422177
E45 & M45
3422480
E40 & M40
14
Pin Options:
1
3422178
E45 & M45
3422844
E40 & M40
15
Pin Options:
1
3422179
E45A & M45A
3422806
E45AJ, M45AJ, E40AJP & M40AJP
16
Pin Options:
1
3422180
E45A & M45A
3422582
E45AJ, M45AJ, E40AJP & M40AJP
17
4844467
Boom Rest Weldment
1
18
0561076
Block, Boom Rest
1
19
3841203
Keeper, Pin - 1/2”
A/R
20
3841143
Keeper, Pin - 3/8”
A/R
21
3780184
O-Ring - 2” (E45, M45, E45AJ & M45AJ Only)
30
22
3780181
O-Ring - 1” (E45 & M45 Only)
4
23
3020022
Grease
A/R
24
0641506
Bolt 5/16”-18NC x 3/4”
4
25
3311505
Locknut 5/16”-18NC
4
26
0641608
Bolt 3/8”-16NC x 1”
5
27
0641610
Bolt 3/8”-16NC x 1 1/4”
4
28
4751600
Flatwasher 5/16”
8
29
Not Used
30
3311605
Locknut 3/8”-16NC
3
31
0641812
Bolt 1/2”-13NC x 1 1/2”
6
32
0940048
Bumper
1
33
0641806
Bolt 1/2”-13NC x 3/4”
2
34
3422669
Pin
1
35
3311805
Locknut 1/2”-13NC
3
36 to 39
Not Used
40
Tube
1
4566356
E45 & M45
4566427
E40 & M40
41
Not Used
42
4751500
Flatwasher 5/16”
4
43
Not Used
44
0100011
Loctite #242
A/R
45
0641810
Bolt 1/2”-13NC x 1 1/4”
12
46
4846091
Rest, Boom (S/N 46063 to Present Only)
1
FIGURE 3-1. BOOMS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
