JLG E45A_AJ Parts Manual - Manual (Page 137)

3120885 5-27
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-12. TELESCOPE CYLINDER ASSEMBLY (E40 & M40)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1683911 TELESCOPE CYLINDER ASSEMBLY Ref. 2/B
1 1683912 Barrel Weldment 1
1A 1120110 Cap, End 1
2 1683980 Rod Weldment 1
3 3480239 Piston 1
4 1683863 Head 1
5 4567963 Spacer, Tube 1
6 4640807 Counterbalance Valve Assembly (See Items 101-103
for Breakdown)
1
7 0641512 Bolt 5/16"-18NC x 1 1/2" 4
8 2220883 Plug, O-Ring 2
9 3951402 Setscrew 1/4"-20NC x 1/4" 1
10 3322205 Locknut 1
11 3760318 Ring, Retaining 1
12 Kit Ring, Wear 2
13 Kit Seal, Cap 1
14 Kit O-Ring 1
15 Kit Ring, Wear 1
16 Kit O-Ring 1
17 Kit Seal, Rod 1
18 Kit Wiper 1
19 0100011 Loctite #242 A/R
20 Not Used
21 2220628 Fitting, 90° 1
22 2220516 Fitting, Cap 1
23 3340882 Wear Pad Assembly 1
24 0641424 Bolt 1/4”-20NC x 3” 2
25 2220596 Fitting, 90° 1
26 2220517 Fitting, Cap 1
27 3311405 Flatwasher 1/4” 4
— — — — — — — — — —
2901903 Seal Kit (Includes Items 12-18) 1
4640807 COUNTERBALANCE VALVE ASSEMBLY Ref.
101 4640771 Cartridge, Counterbalance 1
102 4640709 Cartridge, Vented Counterbalance 1
103 3790113 O-Ring (Between Valve and Cylinder Block) 2
— — — — — — — — —
2900770 Seal Kit (1 Per Cartridge)
